Garhauer -01 Fiddle Blocks - D_Shackle

Fiddle Blocks with Adjustable D-Shackle

25-01US, WL 520kg

5mm adjustable swivel shackle
Delrin ball bearings
Sheave Diameter 50mm (2")
Takes line up to 10mm

27-01US, WL 544kg

6mm adjustable swivel shackle
Delrin ball bearings
Sheave Diameter 57mm (2 1/4")
Takes line up to 10mm

30-01US, WL 907kg

6mm adjustable swivel shackle
Delrin ball bearings
Sheave Diameter 63mm (2 1/2")
Takes line up to 12 mm

35-01US, WL 1587kg

8mm adjustable swivel shackle
Torlon ball bearings and needle rollers
Sheave Diameter 63mm (2 1/2″)
Takes line up to 13mm

40-01US, WL 1270kg

8mm adjustable swivel shackle
Torlon ball bearings
Sheave Diameter 63mm (2 1/2")
Takes line up to 12 mm

50-01US, WL 1360kg

10mm adjustable swivel shackle
Torlon ball bearings
Sheave Diameter 76mm(3″)
Takes line up to 16 mm

70-01US, WL 2267kg

10mm adjustable swivel shackle
Torlon ball bearings
Sheave Diameter 108mm(4 1/4")
Takes line up to 20 mm
